24kW Solar hybrid system installation for Farms, Hotels, Hospitals, medium SMES

Solar companies in Kenya

What is a 3PH 24kW Hybrid Solar Solution?

A 3-phase 24kW hybrid solar system integrates solar power generation, battery storage, and grid connectivity to meet the energy needs of commercial facilities like hotels or health centers..

The hybrid design allows it to operate on-grid (feeding excess power to the utility) or off-grid (using stored battery power during outages), with 3-phase output to support heavy electrical loads common in such facilities.

At Bills On Solar EA Limited is your best solar company in Kenya

Key Components:

Solar Panels (24kW capacity): Approximately 40-48 high-efficiency monocrystalline panels (500-600W each), generating 66-88 kWh daily, depending on sunlight (4-6 peak sun hours).

• Hybrid Inverter (24kW): Manages energy flow between panels, batteries, grid, and loads, often with dual MPPT for optimal solar capture (e.g., GoodWe ET series 15-30kW range, DEYE 20kW, Huawei 30kW, SMA 25kW).

• Battery Storage (e.g., 40kWh LiFePO4): Stores excess solar energy for nighttime, outages, or peak demand, using reliable lithium-ion batteries (e.g., BYD, GoodWe, Uhome, Weco, Deye cells, 6000 cycles).

• Grid Connection: Enables net metering to sell surplus power and draw grid power when needed.

• Monitoring System: Wi-Fi-enabled apps (e.g., Deye Cloud, Sems) for real-time energy tracking and management.

• Benefits of a 3PH 24kW Hybrid Solar System for Hotels, Farms, petrol stations and Health Facilities

• Reliable Power Supply: Ensures uninterrupted operation for critical systems (e.g., medical equipment, HVAC) during outages via battery backup.

• Cost Savings: Reduces electricity bills by using solar and stored energy, with potential revenue from selling excess power via net metering.

• Sustainability: Lowers carbon footprint, enhancing brand image for eco-conscious guests or patients.

• High Capacity: Supports heavy 3-phase loads, ideal for hotels with amenities or health facilities with medical equipment.

• Scalability: Expandable with additional panels or batteries for growing energy needs (e.g., EV charging stations).

• Smart Management: Advanced monitoring optimizes energy use, reducing waste and improving efficiency.

• What Can a 3PH 24kW Hybrid Solar System Power?

• A 24kW hybrid solar system with 40kWh battery storage generates approximately 66-88 kWh daily and can store 40kWh for use during non-sunny periods or outages.

• This capacity suits the high energy demands of hotels, farms, petrol stations and health facilities.

• Below are examples of what it can power:

• Hotels:HVAC Systems: Multiple air conditioning units (e.g., 5-6 units at 2-3 kW each) for guest rooms, lobbies, and dining areas.

• Lighting: LED lighting across guest rooms, hallways, and common areas (1-2 kW total).

• Kitchen Equipment: Commercial refrigerators, ovens, and dishwashers (3-5 kW).

• Water Heating: Electric water heaters or heat pumps for guest bathrooms (2-4 kW).

• Elevators: Small passenger elevators (3-5 kW during operation).

• Laundry Systems: Industrial washing machines and dryers (3-5 kW).

• Miscellaneous: TVs, Wi-Fi routers, computers, and charging stations (1-2 kW).

• Example: A mid-sized hotel with 20-30 rooms, running 4 AC units (8 kW), lighting (2 kW), kitchen appliances (4 kW), and laundry (3 kW) consumes ~40-50 kWh daily.

• The system covers 80-100% of this demand, with batteries powering nighttime or peak loads.

• Health Facilities:

• Medical Equipment: Diagnostic machines (e.g., X-ray, ultrasound, 2-5 kW), vaccine refrigerators (0.5-1 kW), and sterilization units (1-2 kW).

• HVAC and Ventilation: Air conditioning and air filtration systems for patient comfort and infection control (5-10 kW).

• Lighting: High-intensity LED lights for operating rooms and clinics (1-3 kW).

• Office Equipment: Computers, monitors, and communication systems (1-2 kW).

• Backup Power: Critical systems during outages, ensuring continuous operation of life-saving equipment.

• Example: A rural health unit with an estimated load of 20-30 kWh/day (Category III, per USAID) can be fully powered, including vaccine refrigeration, lighting, and medical equipment, with battery backup for emergencies.

• Additional Capabilities:

• EV Charging: Partial charging for electric vehicles (e.g., 7 kW Level 2 chargers for staff or guest vehicles).

• Peak Load Management: Batteries offset peak demand charges, saving costs during high-rate periods.

• Why Choose a 3PH 24kW Hybrid Solar System for Hotels and Health Facilities?High-Power 3-Phase Support: Balances heavy loads across three phases, preventing overloads and ensuring stability for large equipment.

• Energy Resilience: Critical for health facilities requiring uninterrupted power for patient care and hotels aiming for guest satisfaction.

• Eco-Friendly Branding: Attracts eco-conscious guests or patients, enhancing reputation

• Cost-Effective: Reduces energy costs by up to 7% compared to battery-only systems, with 20% higher solar self-consumption.

• Flexible Installation: Requires ~110-170 m² of roof or ground space, suitable for most commercial properties.
