5.12kWh HV dyness lithium ion battery
Ksh 144,999
Ksh 125,000
The Dyness STACK100 5.12kWh (Model S51100) is a high-voltage, stackable LiFePO4 (LFP) energy storage module designed for residential and light commercial applications.
Key Specifications
Nominal Energy: 5.12 kWh per module (Usable energy: ~4.864 kWh)
Nominal Voltage / Capacity: 51.2 V / 100 Ah per module
Chemistry: Lithium Iron Phosphate (LiFePO4 / LFP)
Cycle Life: ≥ 8,000 cycles
Module Weight: 47 kg
Warranty: 10-year manufacturer warranty [1, 2]
System Scalability & Design
Single Cluster Range: Requires a minimum of 3 modules (15.36 kWh) up to 15 modules (76.8 kWh) per stack.
Parallel Expansion: Expandable up to 12 clusters in parallel, reaching a maximum system capacity of 921.6 kWh.
Installation: Rackless, plug-and-play design featuring a base unit and a Smart Battery Distribution Unit (SBDU) controller box on top.
Safety: Built-in aerosol fire suppression system per module and integrated Wi-Fi for remote diagnostics
Frequently Asked Questions
What is the power rating of the 5.12kWh HV dyness lithium ion battery?
The 5.12kWh HV dyness lithium ion battery is rated at 4998W.
What category does the 5.12kWh HV dyness lithium ion battery belong to?
The 5.12kWh HV dyness lithium ion battery is part of our Lithium Ion Battery range.
How much does the 5.12kWh HV dyness lithium ion battery cost?
The 5.12kWh HV dyness lithium ion battery is priced at Ksh 125,000.
